| Product Title | Type | Input Voltage Range | Output Voltage Range | Output Current | Operating Frequency | Static Power Consumption | Packaging | Note | Production | Link |
|---|---|---|---|---|---|---|---|---|---|---|
| PW5150 | Synchronous Rectification Boost Converter | 0.8V~ 5V | 5V | 500mA（VIN=3.7V） | 1.4MHZ | 1.2uA | SOT23-6L | EN True Shutdown Boost 5V Output Chip | Mass Production | Detail |
| PW4004A | Charge Pump | 2.7V～4.5V | 4.95V | 230mA | 380KHZ | 0.4mA | SOT23-6L | A 5V boost circuit with three capacitors in the periphery | Mass Production | Detail |
| PW5300A | Asynchronous | 2.2V~16V | 3V~20V | 1.2A（Vout=5V） | 1.2MHZ | 100uA | SOT23-6L | Detail | ||
| PW5012 | Asynchronous | 2.7V~12V | 3V~15.5V(Withstand voltage of 18V) | 2A（VIN=7.2V，VOUT=12V） | 360KHZ | 300uA | SOP8-EP | Detail | ||
| PW5020 | Asynchronous | 2.5V~18V | 3V~20V | 3A（VIN=7.2V，VOUT=12V） | 1.0MHZ | 0.78mA | SOP8-EP | Detail | ||
| PW5103 | Synchronous | 0.7V~ 5V | 2.0V~ 5V | 600mA | 1.2MHZ | 10uA | SOT23-5L | Detail | ||
| PW5600 | Synchronous | 2.7V~14V | 4.5~14.5V | 3A( Vout:9V ) | ≥2.2MHZ | 120uA | DFN-20 | Detail | ||
| PW5620 | Synchronous | 2.7V~20V | 4.5V~21V | 2A（Vout：15V） | ≥2.2MHZ | 420uA | DFN-20 | Detail | ||
| PW5303 | Synchronous | 2.4V~4.5V | 3.0V~5.5V | 3.3A （5.0V） | 500KHZ | 270uA | SOP8-EP | Detail | ||
| PW6276 | Synchronous | 2.5V~4.4V | 3.0V~5.2V | 2.4A （5.0V） | 500KHZ | 250uA | SOP8-EP | Detail | ||
| PW5410B | Charge Pump | 1.8V～5.0V | 3.3V(Fixed) | 250mA | 1.2MHZ | 650uA | SOT23-6L | Detail | ||
| PW5410A | Charge Pump | 2.7V～5.0V | 5V(Fixed) | 250mA | 1.2MHZ | 1.8mA | SOT23-6L | Detail | ||
| PW5328B | Asynchronous | 2V～24V | ＞28V | 1.2A（Vout=6V） | 1.2MHZ | 200uA | SOT23-6L | Detail | ||
| PW5300 | Asynchronous | 2.6V～5.5V | ＞12V | 1.2A（Vout=5V） | 1.0MHZ | 200uA | SOT23-6L | Detail | ||
| PW5200A | Synchronous | 1.0V~4.4V | 2.5V~5V | 500mA | 1.4MHZ | 260uAC | SOT23-6L | Detail | ||
| PW5200C | Synchronous | 2.0V~4.4V | 2.5V~5V | 500mA | 1.4MHZ | 550uA | SOT23-6L | Detail | ||
| PW5100 | Synchronous | 0.7V~ 5V | 3.0V~ 5V | 600mA | 1.2MHZ | 10uA | SOT23-5L | Detail |
