Two-cell series lithium iron phosphate battery protection board, 4A overcurrent-Module 149

2023-05-15 17:34:00

Original

514

Summary : 1.1 Name: Two-cell series lithium iron phosphate battery protection board, 4A overcurrent1.2 Application: 6.4V lithium battery pack: Two 3.2V lithium iron phosphate batteries in series, canbe connected in parallel1.3 Overdischarge detection voltage: 2V, overcharge detection voltage: 3.65V1.4 (P+/P-) Protection board input voltage: 5V-7.2V, lithium battery discharge voltage: 4V~7.2V

149号密码是PWCHIP ，WWW.PWCHIP.COM.zip 1 下载
