- PW4584, 5V 2.4A input, boost charging management board for two-series lithium battery with 6.1V overvoltage protection-Module 133
PW4584, 5V 2.4A input, boost charging management board for two-series lithium battery with 6.1V overvoltage protection-Module 133
-
2023-05-15 15:51:00
-
UA
Original -
480
Summary : 1.1 Name: PW4584, 5V 2.4A input, boost charging management board for two-series lithiumbattery with 6.1V overvoltage protection1.2 Application: Convenient charging devices, etc.1.3 Battery pack: 7.4V lithium battery pack, two series and multiple parallel, fully charged to 8.4V1.4 Input voltage: 5V (charging light on, full light on), input current: 2.4A
