4S Lithium Battery Charging and Discharging Board with 5V2A Input and Output via USB-Module 131
4S Lithium Battery Charging and Discharging Board with 5V2A Input and Output via USB-Module 131
2023-05-15 15:43:00
UA
Original
421
Summary : 1.1 Name: 4S Lithium Battery Charging and Discharging Board with 5V2A Input and Output viaUSBC 1.2 Application: Convenient charging devices, etc.1.3 Battery pack: 14.8V lithium battery pack, four series-connected 3.7V lithium battery packs canbeparallelized, and full charge voltage is 16.8V.1.4 Input (USB1): 5V2A (charging LED on, fully charged LED on, no battery LED flashes)1.5 Output (USB1): 5V2.4A (discharging LED2 on)
