Four-cell series lithium battery charging and discharging board, 5V-9V2A fast charge PD input and 5V2.4A output-Module 115
-
2023-05-15 14:13:00
-
UA
Original -
417
Summary : 1.1 Name: Four-cell series lithium battery charging and discharging board, 5V-9V2A fast chargePD input and 5V2.4A output1.2 Application: Convenient charging devices, etc.1.3 Battery pack: 14.8V lithium battery pack, four in series and multiple in parallel, fully chargedat 16.8V1.4 Input (USB1): 5V2A (charging indicator light, full charge turns on)1.5 Output (USB2): 5V2.4A
