Three-series lithium battery protection board, 10A overcurrent protection-Module 81

2023-05-15 09:44:00

Original

383

Summary : 1.1 Name: Three-series lithium battery protection board, 10A overcurrent protection1.2 Application: 11.1V lithium battery pack, three 3.7V lithium batteries in series, can be parallelizedin multiple groups1.3 Over-discharge detection voltage: 2.7V (per single lithium battery), overcharge detectionvoltage: 4.25V (per single lithium battery)1.4 (P+/P-) protection board input voltage: 9V-12.6V, full charge at 12.6V, discharge voltage ofthree-series lithium battery pack: 8.1V~12.6VInstantaneous current 10A, recommended working current below 5A

81号密码是PWCHIP ，WWW.PWCHIP.COM.zip 1 下载
